STATCOM inverter

The STATCOM converter enables highly dynamic power factor correction in power transmission networks, helping to reduce efficiency losses caused by transformers or long line networks.

Furthermore, the STATCOM converter offers the possibility of voltage stabilization by controlled provision of capacitive and inductive reactive power. Voltage measurement can be performed directly at the inverter terminals or at a higher network level with high-speed data transmission.

The STATCOM inverter can additionally reduce harmonics caused by non-linear loads.

All advantages at a glance

  • Reliable quality

  • Reliable and robust BMS guarantees long battery life

  • State-of-the-art fire protection system (Stat-X 60 E)

  • Compliance with all required regulations

  • Converters are designed for a service life of > 20 years

  • Outstanding flexibility

  • Flexible energy storage solution with high-quality LiFePO4 batteries

  • Plug & Play concept with MSC Hybrid Converter 175 kW to 3 MW, scalable up to > 100 MW

  • Subsequent integration of energy sources / consumers requires minimal effort

  • Modular system: hybrid converter concept enables integration of additional energy sources / consumers such as PV, wind or hydrogen electrolysers

  • Compact, modular solution in an ISO container (optional in-house solution)

Configurations

BESS FQ

Inverter Container converter Battery storage Container battery storage
Inverter 0.5 MW Inverter integrated in battery container 1 MWh 40 ft
Inverter 0.7 MW Inverter integrated in battery container 1 MWh 40 ft
Inverter 1 MW Inverter integrated in battery container 1 MWh 40 ft
Inverter 0.5 MW 20 ft 1.4 MWh 40 ft
Inverter 0.7 MW 20 ft 1.4 MWh 40 ft
Inverter 1 MW 20 ft 1.4 MWh 40 ft
Inverter 1.5 MW 20 ft 1.4 MWh 40 ft
Inverter 2 MW 40 ft 1.4 MWh 40 ft
Inverter 3 MW 40 ft 1.4 MWh 40 ft
Inverter 4 MW 40 ft 2.8 MWh 2 x 40 ft
Inverter 5 MW 40 ft 2.8 MWh 2 x 40 ft
Inverter 6 MW 40 ft 2.8 MWh 2 x 40 ft
